SAMWAY CRIMPING MACHINE
SAMWAY CRIMPING MACHINE, MODEL: P16HP
Specification：
Main Specification SAMWAY P16HP
Max Hydraulic Hose 1" 3 wire
Crimping Range mm 16528
Die Type P16
Master Die Length mm 64
Max Opening mm 20
Hand Pump Enerpac two stage pump 700 bar
Crimping Force KN 1000
Control Micro Dail
L*W*H mm 330*400*280
Weight KG 25
SAMWAY CRIMPING MACHINE, MODEL: YL20
TECHNICAL DATA
Max Hose Size 1 1/4"
Crimping Range ( mm ) ψ4…ψ87
Die Type 32
Max.Opening ( mm ) 26
Master Die ( Die / Length ) 80
Motor ( kw ) 3.6
Voltage ( v ) 220 / 440
Pump ( l/min ) 13.5
Crimping Force ( kN ) 1700
Crimping Hour 1800
Noise level ( dB(A) ) 71
Protection Class IP54
Length*Width*Height( mm ) 680*600*1350
Weight ( kg ) 230
SAMWAY CRIMPING MACHINE, MODEL: YL32S
TECHNICAL DATA
Max Hose Size 2"
Crimping Range ( mm ) ψ4…ψ87
Die Type 32
Max.Opening ( mm ) 32
Master Die ( Die / Length ) 80
Motor ( kw ) 3.6
Voltage ( v ) 220 / 440
Pump ( l/min ) 13.5
Crimping Force ( kN ) 2200
Crimping Hour 1200
Noise level ( dB(A) ) 71
Protection Class IP54
Length*Width*Height( mm ) 680*600*1400
Weight ( kg ) 270
SAMWAY CRIMPING MACHINE, MODEL: YL20
TECHNICAL DATA Max Hose Size 1 1/4" Crimping Range ( mm ) ψ4…ψ87 Die Type 32 Max.Opening ( mm ) 26 Master Die ( Die / Length ) 80 Motor ( kw ) 3.6 Voltage ( v ) 220 / 440 Pump ( l/min ) 13.5 Crimping Force ( kN ) 1700 Crimping Hour 1800 Noise level ( dB(A) ) 71 Protection Class IP54 Length*Width*Height( mm ) 610*600*600 Weight ( kg ) 200
SAMWAY CRIMPING MACHINE, MODEL: P20HP
Specification：
Main Specification SAMWAY P20HP
Max Hydraulic Hose 1 ½" 4SP
Crimping Range mm 27485
Die Type P20
Master Die Length mm 80
Max Opening mm 25
Hand Pump Enerpac two stage pump 700 bar
Crimping Force KN 1400
Control Micro Dail
L*W*H mm 487*440*270
Weight KG 55
